System Format
3–Way
Frequency Response, Installed (-6dB)
36 Hz – 60 kHz
Sensitivity (2.83Vrms@1m, Installed)
89 dB
Nominal Impedance
4 Ohms
Minimum Impedance (20Hz to 20kHz)
4.5 Ohms @ 1.2 kHz
Maximum Peak SPL (AES75, Z-weighted)
123 dB
Continuous Power Handling (CTA 426-B)
300 W
Recommended Amplifier Power (RMS, Music Signal)
150 – 600 W into 4 ohms
75 – 300 W into 8 ohms
Bass Alignment
Sealed
Crossover Frequency
LF/HF: 700 kHz
MF/HF: 3.25 kHz
Drive Unit Complement
4 x 5″ (127 mm) RDT III bass driver
1 x 3″ (76 mm) C-CAM midrange driver
1 x MPD II transducer
Mounting Depth
85 mm (33/8“)
Cutout L x W
880 x 202 mm (345/8 x 715/16“)
Pre-Construction Bracket
WL-B
External Dimensions with all accessories fitted (H x W x D)
909 x 231 x 93 mm (221/16 x 91/8 x 39/16“)
Weight (each)
12.4 kg (27 lb 5 oz)
Cabinet Finish
Matte black & Orange & Green
Sold As
Single Unit
Warranty
Lifetime
