System Format
2–Way
Channels
1
Frequency Response, Installed (-6dB)
35 Hz – 35 kHz
Nominal Impedance
8 ohm
Minimum Impedance (20Hz to 20kHz)
6.6 Ohm @ 150 Hz
Sensitivity (2.83Vrms@1m, Installed)
86 dB
Maximum Peak SPL* (single speaker @ 1m Z-Weighted)
114 dB
Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)
75 W
Recommended Amplifier Power (RMS into 8 OHM, Music Signal)
40 – 150 W
Drive Unit Complement
1 x 7″ (178 mm) RST II mid-bass driver
1 x 1″ x (25 mm) C-CAM tweeter
Crossover Frequency
LF/HF: 2.25 kHz
Mounting Depth
99 mm (37/8″)
Cut-Out Hole Diameter
212 mm (83/8“)
External Dimensions (Including Grille (H x W x D))
242 x 242 x 103 mm (91/2 x 91/2 x 44/16“)
Weight (each)
2 kg (4 lb 6 oz)
Pre-Construction Bracket
CM-B
Cabinet Finish
Matte black & Orange & Bronze
Sold As
Single Unit with CM-Round Grille (white)
Corner Switch
On/Off
HF Switch
– /0/ +
Warranty
Lifetime
