System Format
2–Way
Channels
1
Frequency Response, Installed (-6dB)
75 Hz – 25 kHz
Nominal Impedance
8 Ohm
Minimum Impedance (20Hz to 20kHz)
6.6 Ohm @ 10 kHz
Sensitivity (2.83Vrms@1m, Installed)
89 dB
Maximum Peak SPL* (single speaker @ 1m Z-Weighted)
120 dB
Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)
100 W
Recommended Amplifier Power (RMS into 8 OHM, Music Signal)
50 – 200 W
Drive Unit Complement
1 x 9″ (229 mm) RST II bass driver
1 x 1.25″ (32 mm) C-CAM tweeter
Crossover Frequency
LF/HF: 2.25 kHz
Bass Alignment
Sealed
Mounting Depth
177.5 mm (663/64“)
Cut-Out Hole Diameter
248 mm
External Dimensions (Including Grille (H x W x D))
278 x 278 x 181 mm (1015/16 x 1015/16 x 71/8“)
Weight (each)
3.3 kg (7 lb 5 oz)
Pre-Construction Bracket
CL-B
Cabinet Finish
Matte black & Orange & Bronze
Sold As
Single Unit with CL-Round Grille (white)
Corner Switch
On/Off
HF Switch
– /0/ +
Warranty
Lifetime
