System Format
2–Way
Channels
1
Frequency Response, Installed (-6dB)
40 Hz – 30 kHz
Nominal Impedance
8 ohm
Minimum Impedance (20Hz to 20kHz)
6.6 Ohm @ 150 Hz
Sensitivity (2.83Vrms@1m, Installed)
84 dB
Maximum Peak SPL* (single speaker @ 1m Z-Weighted)
110 dB
Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)
50 W
Recommended Amplifier Power (RMS into 8 OHM, Music Signal)
25 – 100 W
Drive Unit Complement
1 x 5″ (127 mm) C-CAM mid-bass driver
1 x 1″ (25 mm) C-CAM tweeter
Crossover Frequency
LF/HF: 3 kHz
Mounting Depth
99 mm (37/8”)
Cut-Out Hole Diameter
171 mm (63/4”)
External Dimensions (Including Grille (H x W x D))
201 x 201 x 103 mm (715/16 x 715/16 x 44/16“)
Weight (each)
1.4 kg (3 lb 1 oz)
Pre-Construction Bracket
CS-B
Cabinet Finish
Matte black & Orange
Sold As
Single Unit with CS-Round Grille (white)
Warranty
Lifetime
