TRZ-300W
300B class A parallel single ended integrated amplifier
| Circuit system | 300B class A parallel single ended integrated amplifier |
| Tubes | 300B x 4, 12AX7 x 2, 12AU7 x 2 |
| Bias | Fixed bias, adjustable with bias meter |
| Output power | 20W+20W at 8 ohms |
| Frequency response | 5Hz-68kHz(-3dB) |
| S/N ratio | 93dB |
| Input sensitivity | LINE 480mV, MM 2.5mV, MAIN IN 920mV |
| Input impedance | LINE 100k ohm, MM 47k ohm, MAIN IN 10k ohm |
| Input terminals | RCA unbalanced x 6(LINE1-4 , MM x 1, MAIN IN x 1) |
| Output terminals | TAPE OUT x 1(RCA unbalanced) |
| Speaker output terminals | 4~8 ohms |
| Equipped components | High quality speaker terminal |
| Other functions | Remote control (Volume , Mute, Input select)
Bias adjuster with bias meter |
| Power consumption | 240W (210W/No signal) |
| Dimensions | W440mm x D370mm x H220mm |
| Weight | 34.0kg |
| Accessories | Tube cover , Remote control |
