TRV-88SER
KT88 AB class push-pull ended integrated amplifier
| Circuit system | KT88 AB class push-pull ended integrated amplifier |
| Maximum output | 35W+35W (8ohms) |
| Frequency response | 10Hz-100kHz(-1,-4dB) |
| S/N ratio | 90dB |
| Input sensitivity | LINE 400mV , MM 2.5mV |
| Input impedance | LINE 100k ohm , MM 47k ohm |
| Input terminals | RCA unbalanced*3(LINE1-3) , MM*1 |
| Output terminals | TAPE OUT*1 |
| Speaker output terminals | 6 — 8 ohms |
| Headphone output | 6.3mm stereo jack |
| Equipped components | KOA high precision resistors (Japan),High quality coupling capacitors,High quality speaker terminal (USA) |
| Other functions | Remote control (Volume , Mute) |
| Dimensions | W345mm*D320mm*H185mm |
| Weight | 17kg |
| Accessories | Tube cover , Wooden side plates , Remote control |
