KT150 class AB push-pull integrated amplifier
| Circuit system | KT150 class AB push-pull integrated amplifier |
| Tubes | KT150 x 4, 12AU7 x 4 |
| Bias | Fixed bias, adjustable with bias meter |
| Output power | 100W+100W at 8 ohms |
| Frequency response | 8Hz-70kHz(-3dB) |
| S/N ratio | 93dB |
| Input sensitivity | LINE 480mV, MM 2.5mV, MAIN IN 920mV |
| Input impedance | LINE 100k ohm, MM 47k ohm, MAIN IN 10k ohm |
| Input terminals | RCA unbalanced x 6(LINE1-4 , MM x 1, MAIN IN x 1) |
| Output terminals | TAPE OUT x 1(RCA unbalanced) |
| Speaker output terminals | 4～8 ohms |
| Equipped components | High quality speaker terminal |
| Other functions | Remote control (Volume , Mute, Input select) Bias adjuster with bias meter |
| Power consumption | 520W (190W/No signal) |
| Dimensions | W440mm x D370mm x H220mm |
| Weight | 34.5kg |
| Accessories | Tube cover , Remote control |
